SI2305CDS-T1-GE3

Name: SI2305CDS-T1-GE3
Brand: Vishay
SKU: 320998
Availability: InStock
Rating: 4.93 (48 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	SI2305CDS-T1-GE3
Manufacturer	Vishay
Catalog	Transistors - FETs, MOSFETs - RF
Description	MOSFET P-CH 8V 5.8A SOT23-3 / Trans MOSFET P-CH 8V 4.4A 3-Pin SOT-23 T/R
Datasheet	SI2305CDS-T1-GE3 Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Discrete Semiconductor Products
Manufacturer	Vishay
Packaging	Reel - TR
Status	Active
Polarity	P-Channel
Technology	MOSFET
Drain-Source Breakdown Voltage	8V
Continuous Drain Current at 25°C	5.8A (Tc)
Drive Voltage (Max Rds On, Min Rds On)	1.8V, 4.5V
Gate-Source Threshold Voltage	1V @ 250μA
Max Gate Charge	30nC @ 8V
Max Input Capacitance	960pF @ 4V
Maximum Gate-Source Voltage	±8V
Power Dissipation (Max)	960mW (Ta), 1.7W (Tc)
Maximum Rds On at Id,Vgs	35 mOhm @ 4.4A, 4.5V
Temperature Range - Operating	-55°C to 150°C (TJ)
Mounting	SMD (SMT)
Case / Package	SOT-23-3 (TO-236)
Dimension	TO-236-3, SC-59, SOT-23-3
Win Source Part Number	028369-SI2305CDS-T1-GE3
Is this a common-used part?	Yes
Popularity	High
Supply and Demand Status	Sufficient
Application Field	Used in Industrial, Power Management, Portable Devices
Family Name	Si2305CDS
Introduction Date	July 07, 2009
ECCN	EAR99
Halogen Free	Compliant
Estimated EOL Date	2027
Ultra Librarian 3D Model	Ultra Librarian SI2305CDS-T1-GE3 CAD Model

Alternative Products

Description

The Vishay 028369-SI2305CDS-T1-GE3 is a P-channel MOSFET that is used in a variety of applications, including power management, industrial, and portable devices.

Maximum Power Dissipation: 960mW
Family: Si2305CDS
Popularity: High
Supply and Demand Status: Sufficient
Breakdown Voltage: 8V
Continuous Drain Current @ 25°C: 5.8A
Maximum Rds On @ Id, Vgs: 35 mOhm @ 4.4A, 4.5V
Package: SOT-23-3
Operating Temperature Range: -55°C to 150°C (TJ)
