Same model may have multiple batches, images only for reference.

SI7489DP-T1-E3

Name: SI7489DP-T1-E3
Brand: Vishay
SKU: 666794
Availability: InStock
Rating: 4.85 (48 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	SI7489DP-T1-E3
Manufacturer	Vishay
Catalog	Transistors - FETs, MOSFETs - RF
Description	P-Channel 100-V (D-S) MOSFET
Datasheet	SI7489DP-T1-E3 Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Discrete Semiconductor Products
Manufacturer	Vishay
Series	TrenchFET
Packaging	Reel - TR
Channel Type Type	P
Technology	MOSFET
Drain Source Voltage	100V
Current - Continuous Drain (Id) @ 25°C	28A (Tc)
Drive Voltage (Max Rds On, Min Rds On)	4.5V, 10V
Vgs(th) (Maximum) @ Id	3V @ 250μA
Gate Charge (Qg) (Maximum) @ Vgs	160nC @ 10V
Input Capacitance (Ciss) (Maximum) @ Vds	4600pF @ 50V
Vgs (Maximum)	±20V
Power Dissipation (Maximum)	5.2W (Ta), 83W (Tc)
Rds On (Maximum) @ Id, Vgs	41 mOhm @ 7.8A, 10V
Operating Temperature Range	-55°C ~ 150°C (TJ)
Mounting	SMD
Manufacturer Package	PowerPAK SO-8
Package	PowerPAK SO-8
Win Source Part Number	1249482-SI7489DP-T1-E3
Manufacturer Homepage	www.vishay.com
Is this a common-used part?	Yes
Popularity	High
Supply and Demand Status	Limited
Application Field	Used in Power Management
Ultra Librarian 3D Model	Ultra Librarian SI7489DP-T1-E3 CAD Model

Alternative Products

Description

The Vishay SI7489DP-T1-E3 is a power MOSFET transistor from the TrenchFET series used in power management applications.

Maximum Drain-Source Voltage: 100V
Continuous Drain Current @ 25°C: 28A
Package: PowerPAK SO-8
Gate-Source Threshold Voltage: 3V
Maximum Gate-Source Voltage: ±20V
Maximum Power Dissipation @ Ta: 5.2W
Maximum Power Dissipation @ Tc: 83W
Rds On @ 7.8A, 10V: 41 mOhm
