SQJ481EP-T1_GE3

Name: SQJ481EP-T1_GE3
Brand: Vishay
SKU: 976147
Availability: InStock
Rating: 4.93 (5 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	SQJ481EP-T1_GE3
Manufacturer	Vishay
Catalog	Transistors - FETs, MOSFETs - RF
Description	MOSFET P-CH 80V 16A PPAK SO-8
Datasheet	SQJ481EP-T1_GE3 Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Discrete Semiconductor Products - Transistors - FETs, MOSFETs - Single FETs, MOSFETs
Mfr	Vishay
Series	Automotive, AEC-Q101, TrenchFET®
Package	Tape & Reel
Product Status	Active
FET Type	P-Channel
Technology	MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss)	80 V
Current - Continuous Drain (Id) @ 25°C	16A (Tc)
Drive Voltage (Max Rds On, Min Rds On)	4.5V, 10V
Rds On (Max) @ Id, Vgs	80mOhm @ 10A, 10V
Vgs(th) (Max) @ Id	2.5V @ 250µA
Gate Charge (Qg) (Max) @ Vgs	50 nC @ 10 V
Vgs (Max)	±20V
Input Capacitance (Ciss) (Max) @ Vds	2000 pF @ 25 V
Power Dissipation (Max)	45W (Tc)
Temperature Range - Operating	-55°C ~ 175°C (TJ)
Mounting Type	Surface Mount
Supplier Device Package	PowerPAK® SO-8
Package / Case	PowerPAK® SO-8
Base Product Number	SQJ481
Standard Package	3,000 pcs
MSL Level	1 (Unlimited)
ECCN	EAR99
HTSUS	8541.29.0095
Win Source Part Number	976147-SQJ481EP-T1_GE3
Ultra Librarian 3D Model	Ultra Librarian SQJ481EP-T1_GE3 CAD Model

Alternative Products

Description

The SQJ481EP-T1_GE3 is a P-channel MOSFET designed for surface mount applications.

Category: Automotive Series, Discrete Semiconductor Products
Drain to Source Voltage: 80V
Continuous Drain Current: 16A @ 25°C
Maximum On-Resistance: 80mOhm @ 10A and 10V Gate-Source Voltage
Gate Charge: 50nC @ 10V
Input Capacitance: 2000pF @ 25V Drain-Source Voltage
Power Dissipation: 45W
Operating Temperature: -55°C to 175°C
Package: PowerPAK SO-8
Packaging: Tape and Reel
Product Status: Active
