IRFR3806TRPBF Real Image IRFR3806TRPBF real image363
Same model may have multiple batches, images only for reference.
IRFR3806TRPBF Real Image IRFR3806TRPBF real image363
IRFR3806TRPBF Real Image IRFR3806TRPBF real image363
Same model may have multiple batches, images only for reference.

IRFR3806TRPBF

Part No IRFR3806TRPBF
Manufacturer Infineon Technologies
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET N-CH 60V 43A DPAK
Datasheet
IRFR3806TRPBF Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Infineon Technologies
Packaging Reel - TR
Status Active
Polarity N-Channel
Technology MOSFET
Drain-Source Breakdown Voltage 60V
Continuous Drain Current at 25°C 43A (Tc)
Drive Voltage (Max Rds On, Min Rds On) 10V
Gate-Source Threshold Voltage 4V @ 50μA
Max Gate Charge 30nC @ 10V
Max Input Capacitance 1150pF @ 50V
Maximum Gate-Source Voltage ±20V
Power Dissipation (Max) 71W (Tc)
Maximum Rds On at Id,Vgs 15.8 mOhm @ 25A, 10V
Temperature Range - Operating -55°C to 175°C (TJ)
Mounting SMD (SMT)
Case / Package D-Pak
Dimension TO-252-3, DPak (2 Leads + Tab), SC-63
Win Source Part Number 107624-IRFR3806TRPBF
Family Name IRFR3806
Introduction Date March 04, 2008
ECCN EAR99
Country of Origin China, Mexico
Halogen Free Compliant
Estimated EOL Date 2024
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian IRFR3806TRPBF CAD Model

Description

The Infineon Technologies 107624-IRFR3806TRPBF is an N-Channel MOSFET transistor with a maximum power dissipation of 71W (Tc) and a continuous drain current at 25°C of 43A (Tc).

  • Maximum Rds On: 15.8 mOhm @ 25A, 10V
  • Maximum Gate-Source Voltage: ±20V
  • Supply and Demand Status: balanced
