SUD17N25-165-E3 Vishay SUD17N25-165-E3 real image SUD17N25-165-E3 label picture SUD17N25-165-E3 label picture 2
Same model may have multiple batches, images only for reference.
SUD17N25-165-E3 Vishay SUD17N25-165-E3 real image SUD17N25-165-E3 label picture SUD17N25-165-E3 label picture 2
SUD17N25-165-E3 Vishay SUD17N25-165-E3 real image SUD17N25-165-E3 label picture SUD17N25-165-E3 label picture 2
Same model may have multiple batches, images only for reference.

SUD17N25-165-E3

Part No SUD17N25-165-E3
Manufacturer Vishay
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET N-CH 250V 17A TO252
Datasheet
SUD17N25-165-E3 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Vishay
Packaging Reel - TR
Status Obsolete(EOL)
Polarity N-Channel
Technology MOSFET
Drain-Source Breakdown Voltage 250V
Continuous Drain Current at 25°C 17A (Tc)
Drive Voltage (Max Rds On, Min Rds On) 10V
Gate-Source Threshold Voltage 4V @ 250μA
Max Gate Charge 42nC @ 10V
Max Input Capacitance 1950pF @ 25V
Maximum Gate-Source Voltage ±20V
Power Dissipation (Max) 3W (Ta), 136W (Tc)
Maximum Rds On at Id,Vgs 165 mOhm @ 14A, 10V
Temperature Range - Operating -55°C to 175°C (TJ)
Mounting SMD (SMT)
Case / Package TO-252, (D-Pak)
Dimension TO-252-3, DPak (2 Leads + Tab), SC-63
Win Source Part Number 1104084-SUD17N25-165-E3
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Family Name SUD17N25-165
Introduction Date April 07, 2004
ECCN EAR99
Estimated EOL Date Obsolete
Ultra Librarian 3D Model Ultra Librarian SUD17N25-165-E3 CAD Model

Description

The Vishay SUD17N25-165-E3 MOSFET is an N-channel MOSFET that can handle a maximum power dissipation of 3W @ Ta and 136W @ Tc.

  • Power Dissipation (Max): 3W @ Ta and 136W @ Tc
  • Mounting: SMD
  • Package: TO-252 (D-Pak)
  • Drain-Source Breakdown Voltage: 250V
  • Continuous Drain Current: 17A @ 25°C
  • Alternative Cross-Reference: STD18NF25, RCD080N25TL, and STD17N25
  • Introduction Date: April 07, 2004
  • Estimated EOL Date: Obsolete
