SUD50N02-06P-E3 Vishay SUD50N02-06P-E3 Real Image SUD50N02-06P-E3 real image
Same model may have multiple batches, images only for reference.
SUD50N02-06P-E3 Vishay SUD50N02-06P-E3 Real Image SUD50N02-06P-E3 real image
SUD50N02-06P-E3 Vishay SUD50N02-06P-E3 Real Image SUD50N02-06P-E3 real image
Same model may have multiple batches, images only for reference.

SUD50N02-06P-E3

Part No SUD50N02-06P-E3
Manufacturer Vishay
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET N-CH 20V 50A TO252
Datasheet
SUD50N02-06P-E3 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Vishay
Packaging Reel - TR
Status Active
Polarity N-Channel
Technology MOSFET
Drain-Source Breakdown Voltage 20V
Continuous Drain Current at 25°C 50A (Tc)
Drive Voltage (Max Rds On, Min Rds On) 4.5V, 10V
Gate-Source Threshold Voltage 3V @ 250μA
Max Gate Charge 30nC @ 4.5V
Max Input Capacitance 2550pF @ 10V
Maximum Gate-Source Voltage ±20V
Power Dissipation (Max) 6.8W (Ta), 65W (Tc)
Maximum Rds On at Id,Vgs 6 mOhm @ 20A, 10V
Temperature Range - Operating -55°C to 175°C (TJ)
Mounting SMD (SMT)
Case / Package TO-252, (D-Pak)
Dimension TO-252-3, DPak (2 Leads + Tab), SC-63
Win Source Part Number 031611-SUD50N02-06P-E3
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Family Name SUD50N02-06P
Introduction Date September 24, 2002
ECCN EAR99
Country of Origin China
Estimated EOL Date Obsolete
Ultra Librarian 3D Model Ultra Librarian SUD50N02-06P-E3 CAD Model

Description

The Vishay SUD50N02-06P-E3 is a N-Channel MOSFET with a Drain-Source Breakdown Voltage of 20V and Continuous Drain Current of 50A at 25°C.

  • Manufacturer: Vishay
  • Channel Type: N-Channel
  • Drain-Source Breakdown Voltage: 20V
  • Continuous Drain Current: 50A @ 25°C
  • Maximum Rds On: 6 mOhm @ 20A, 10V
  • Gate-Source Threshold Voltage: 3V @ 250μA
  • Maximum Gate-Source Voltage: ±20V
  • Maximum Gate Charge: 30nC @ 4.5V
  • Maximum Input Capacitance: 2550pF @ 10V
  • Operating Temperature Range: -55°C to 175°C (TJ)
  • Package: TO-252, (D-Pak)
  • Dimension: TO-252-3, DPak (2 Leads + Tab), SC-63
