IRLS3036-7PPBF Real Image IRLS3036-7PPBF Real Image
Same model may have multiple batches, images only for reference.
IRLS3036-7PPBF Real Image IRLS3036-7PPBF Real Image
IRLS3036-7PPBF Real Image IRLS3036-7PPBF Real Image
Same model may have multiple batches, images only for reference.

IRLS3036-7PPBF

Part No IRLS3036-7PPBF
Manufacturer Infineon Technologies
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET N-CH 60V 240A D2PAK
Datasheet
IRLS3036-7PPBF Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Infineon Technologies
Packaging Tube/Rail
Status Not For New Designs
Polarity N-Channel
Technology MOSFET
Drain-Source Breakdown Voltage 60V
Continuous Drain Current at 25°C 240A (Tc)
Drive Voltage (Max Rds On, Min Rds On) 4.5V, 10V
Gate-Source Threshold Voltage 2.5V @ 250μA
Max Gate Charge 160nC @ 4.5V
Max Input Capacitance 11270pF @ 50V
Maximum Gate-Source Voltage ±16V
Power Dissipation (Max) 380W (Tc)
Maximum Rds On at Id,Vgs 1.9 mOhm @ 180A, 10V
Temperature Range - Operating -55°C to 175°C (TJ)
Mounting SMD (SMT)
Case / Package D2PAK (7-Lead)
Dimension TO-263-7, D2Pak (6 Leads + Tab), TO-263CB
Win Source Part Number 1047653-IRLS3036-7PPBF
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian IRLS3036-7PPBF CAD Model

Description

The Infineon Technologies MOSFET is an N-channel polarity type.

  • Manufacturer: Infineon Technologies
  • Polarity: N-Channel
  • Drain-Source Breakdown Voltage: 60V
  • Continuous Drain Current: 240A (Tc)
  • Gate-Source Threshold Voltage: 2.5V @ 250μA
  • Maximum Input Capacitance: 11270pF @ 50V
  • Maximum Gate-Source Voltage: ±16V
  • Maximum Rds On at Id,Vgs: 1.9 mOhm @ 180A, 10V
  • Drive Voltage (Max Rds On, Min Rds On): 4.5V, 10V
  • Status: Not for New Designs
  • Package: D2PAK (7-Lead)
  • Mounting Type: SMD (SMT)
  • Supply and Demand Status: Limited
