SUD50N04-8M8P-4GE3 Real Image SUD50N04-8M8P-4GE3 real image6978 SUD50N04-8M8P-4GE3 Real Image
Same model may have multiple batches, images only for reference.
SUD50N04-8M8P-4GE3 Real Image SUD50N04-8M8P-4GE3 real image6978 SUD50N04-8M8P-4GE3 Real Image
SUD50N04-8M8P-4GE3 Real Image SUD50N04-8M8P-4GE3 real image6978 SUD50N04-8M8P-4GE3 Real Image
Same model may have multiple batches, images only for reference.

SUD50N04-8M8P-4GE3

Part No SUD50N04-8M8P-4GE3
Manufacturer Vishay
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET N-CH 40V 14A TO-252
Datasheet
SUD50N04-8M8P-4GE3 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Vishay
Packaging Reel - TR
Status Active
Polarity N-Channel
Technology MOSFET
Drain-Source Breakdown Voltage 40V
Continuous Drain Current at 25°C 14A (Ta), 50A (Tc)
Drive Voltage (Max Rds On, Min Rds On) 4.5V, 10V
Gate-Source Threshold Voltage 3V @ 250μA
Max Gate Charge 56nC @ 10V
Max Input Capacitance 2400pF @ 20V
Maximum Gate-Source Voltage ±20V
Power Dissipation (Max) 3.1W (Ta), 48.1W (Tc)
Maximum Rds On at Id,Vgs 8.8 mOhm @ 20A, 10V
Temperature Range - Operating -55°C to 150°C (TJ)
Mounting SMD (SMT)
Case / Package TO-252, (D-Pak)
Dimension TO-252-3, DPak (2 Leads + Tab), SC-63
Win Source Part Number 031614-SUD50N04-8M8P-4GE3
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian SUD50N04-8M8P-4GE3 CAD Model

Description

The Vishay SUD50N04-8M8P-4GE3 is an N-channel MOSFET designed for discrete semiconductor applications.

  • Package: TO-252 (D-Pak)
  • Drain-Source Breakdown Voltage: 40V
  • Continuous Drain Current: 14A (Ta) and 50A (Tc) @ 25°C
  • Gate-Source Threshold Voltage: 3V @ 250μA
  • Maximum Gate Charge: 56nC @ 10V
  • Maximum Rds On: 8.8 mOhm @ 20A, 10V
  • Operating Temperature Range: -55°C to 150°C (TJ)
  • Supply and Demand Status: limited
