SUM75N15-18P-E3 Vishay SUM75N15-18P-E3 real image SUM75N15-18P-E3 real image 2
Same model may have multiple batches, images only for reference.
SUM75N15-18P-E3 Vishay SUM75N15-18P-E3 real image SUM75N15-18P-E3 real image 2
SUM75N15-18P-E3 Vishay SUM75N15-18P-E3 real image SUM75N15-18P-E3 real image 2
Same model may have multiple batches, images only for reference.

SUM75N15-18P-E3

Part No SUM75N15-18P-E3
Manufacturer Vishay
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET N-CH 150V 75A D2PAK
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Categories Discrete Semiconductor Products
Manufacturer Vishay
Packaging Reel - TR
Status Obsolete(EOL)
Polarity N-Channel
Technology MOSFET
Drain-Source Breakdown Voltage 150V
Continuous Drain Current at 25°C 75A (Tc)
Drive Voltage (Max Rds On, Min Rds On) 10V
Gate-Source Threshold Voltage 4.5V @ 250μA
Max Gate Charge 100nC @ 10V
Max Input Capacitance 4180pF @ 75V
Maximum Gate-Source Voltage ±20V
Power Dissipation (Max) 3.12W (Ta), 312.5W (Tc)
Maximum Rds On at Id,Vgs 18 mOhm @ 20A, 10V
Temperature Range - Operating -55°C to 150°C (TJ)
Mounting SMD (SMT)
Case / Package TO-263 (D2Pak)
Dimension TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Win Source Part Number 212451-SUM75N15-18P-E3
Family Name SUM75N15-18P
Introduction Date April 08, 2008
ECCN EAR99
Halogen Free Compliant
Estimated EOL Date Obsolete
Ultra Librarian 3D Model Ultra Librarian SUM75N15-18P-E3 CAD Model

Description

Vishay's electronic component with the Win Source Part Number 212451-SUM75N15-18P-E3 is a MOSFET with a polarity of N-Channel and a power dissipation of 3.12W (Ta), 312.5W (Tc).

  • Status: obsolete (EOL)
  • Operating Temperature Range: -55°C to 150°C (TJ)
  • Case/Package: TO-263 (D2Pak)
