VS-40EPS08PBF Real Image VS-40EPS08PBF real image9855
Same model may have multiple batches, images only for reference.
VS-40EPS08PBF Real Image VS-40EPS08PBF real image9855
VS-40EPS08PBF Real Image VS-40EPS08PBF real image9855
Same model may have multiple batches, images only for reference.

VS-40EPS08PBF

Part No VS-40EPS08PBF
Manufacturer Vishay
Catalog Diodes, Rectifiers - Single
Description DIODE GEN PURP 800V 40A TO247AC
Datasheet
VS-40EPS08PBF Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Vishay
Packaging Tube/Rail
Status Active
Diode Type Standard
Voltage - DC Reverse (Vr) (Max) 800V
Current - Average Rectified (Io) 40A
Voltage - Forward (Vf) (Max) @ If 1.1V @ 40A
Speed(Frequency) Standard Recovery >500ns, > 200mA (Io)
Current - Reverse Leakage @ Vr 100μA @ 800V
Mounting Through Hole
Case / Package TO-247AC Modified
Operating Temperature - Junction -40°C to 150°C
Win Source Part Number 142593-VS-40EPS08PBF
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian VS-40EPS08PBF CAD Model

Description

The Vishay 142593-VS-40EPS08PBF is a through-hole mounted diode with a standard diode type.

  • Mounting Type: Through-hole
  • Diode Type: Standard Diode
  • Maximum DC Reverse Voltage: 800V
  • Average Rectified Current: 40A
  • Forward Voltage @ 40A: 1.1V
  • Reverse Leakage Current @ 800V: 100μA
  • Operating Temperature Range: -40°C to 150°C
  • Package: TO-247AC modified case
  • Recovery Speed: Standard recovery speed of greater than 500ns
  • Popularity: Medium
