VS-60EPU06PBF Real Image VS-60EPU06PBF real image9858
Same model may have multiple batches, images only for reference.
VS-60EPU06PBF Real Image VS-60EPU06PBF real image9858
VS-60EPU06PBF Real Image VS-60EPU06PBF real image9858
Same model may have multiple batches, images only for reference.

VS-60EPU06PBF

Part No VS-60EPU06PBF
Manufacturer Vishay
Catalog Diodes, Rectifiers - Single
Description DIODE GEN PURP 600V 60A TO247AC
Datasheet
VS-60EPU06PBF Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Vishay
Packaging Tube/Rail
Status Active
Diode Type Standard
Voltage - DC Reverse (Vr) (Max) 600V
Current - Average Rectified (Io) 60A
Voltage - Forward (Vf) (Max) @ If 1.68V @ 60A
Speed(Frequency) Fast Recovery = 200mA (Io)
Reverse Recovery Time (trr) 81ns
Current - Reverse Leakage @ Vr 50μA @ 600V
Mounting Through Hole
Case / Package TO-247AC Modified
Operating Temperature - Junction -55°C to 175°C
Win Source Part Number 057336-VS-60EPU06PBF
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian VS-60EPU06PBF CAD Model

Description

The supply and demand status is balanced.

  • Win Source Part Number: 057336-VS-60EPU06PBF
  • Type: standard diode
  • Voltage - DC Reverse (Vr) (Max): 600V
  • Current - Average Rectified (Io): 60A
  • Case: TO-247AC Modified case
  • Speed: fast recovery = 200mA (Io)
