VS-HFA50PA60CPBF Vishay VS-HFA50PA60CPBF real image
Same model may have multiple batches, images only for reference.
VS-HFA50PA60CPBF Vishay VS-HFA50PA60CPBF real image
VS-HFA50PA60CPBF Vishay VS-HFA50PA60CPBF real image
Same model may have multiple batches, images only for reference.

VS-HFA50PA60CPBF

Part No VS-HFA50PA60CPBF
Manufacturer Vishay
Catalog Diodes, Rectifiers - Arrays
Description Rectifier Diode Switching 50A 75ns 3-Pin(3+Tab) TO-247AC Tube / DIODE ARRAY GP 600V 25A TO247AC
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Vishay
Packaging Tube/Rail
Status Active
Diode Configuration 1 Pair Common Cathode
Diode Type Standard
Voltage - DC Reverse (Vr) (Max) 600V
Current - Average Rectified (Io) (per Diode) 25A (DC)
Voltage - Forward (Vf) (Max) @ If 1.7V @ 25A
Speed(Frequency) Fast Recovery = 200mA (Io)
Reverse Recovery Time (trr) 75ns
Current - Reverse Leakage @ Vr 20μA @ 600V
Operating Temperature - Junction -55°C to 150°C
Mounting Through Hole
Case / Package TO-247AC
Win Source Part Number 1043255-VS-HFA50PA60CPBF
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Family Name VS-HFA50PA60C
Introduction Date March 27, 2007
ECCN EAR99
Country of Origin China
Halogen Free Compliant
Estimated EOL Date Obsolete / End of life
Ultra Librarian 3D Model Ultra Librarian VS-HFA50PA60CPBF CAD Model

Description

The VS-HFA50PA60CPBF is an electronic component manufactured by Vishay.

  • Diode Type: Standard
  • Voltage Rating: 600V
  • Forward Voltage: 1.7V @ 25A
  • Reverse Recovery Time: 75ns
  • Current Rating: 25A
  • Operating Temperature Range: -55°C to 150°C
  • Applications: Rectification, freewheeling, and reverse polarity protection
