The WSL20106L000FEA is a power metal strip resistor manufactured by Vishay. These resistors are known for their high power handling capability and low resistance values, making them suitable for current sensing and shunt applications. The 'WSL' series denotes a wirewound shunt resistor, and the specific model indicates its size and resistance.

Applications

• Current sensing in power supplies
• Shunt resistors for ammeters
• Automotive electronics
• Motor control circuits
• High-current applications

Features

• Resistance value: 0.006 Ohms
• Power rating: 1 Watt
• Tolerance: 1%
• Low inductance
• High pulse load capability
• Small size (2010 package)

Benefits

• Accurate current measurement
• High power handling capability
• Minimal impact on circuit performance due to low inductance
• Reliable performance under pulse load conditions
• Easy to integrate into compact designs

Additional Details

The WSL20106L000FEA has a resistance value of 0.006 Ohms, allowing for precise current sensing with minimal voltage drop. It is capable of handling up to 1 Watt of power, making it suitable for high-current applications. The resistor's low inductance ensures that it has minimal impact on the circuit's performance, even at high frequencies. Its high pulse load capability enables it to withstand short-duration, high-current pulses without damage. The WSL20106L000FEA is available in a 2010 surface-mount package, making it easy to integrate into compact electronic devices. The resistance element is constructed from a metal strip, which provides excellent thermal conductivity and stability. Detailed specifications, including resistance temperature coefficient, pulse load capability, and operating temperature range, can be found in the product datasheet.
