Part No 231-69PABE-15V
Manufacturer Wakefield-Vette
Catalog Thermal - Heat Sinks
Description HEATSINK TO-220 VERT BLK / Heat Sink TO-220 Aluminum 2.0W @ 45°C Board Level, Vertical
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Fans, Thermal Management - Thermal - Heat Sinks
Mfr Wakefield-Vette
Series 231
Package Box
Type Board Level, Vertical
Package Cooled TO-220
Attachment Method Bolt On and Board Mounts
Shape Rectangular, Fins
Length 0.690" (17.53mm)
Width 0.835" (21.21mm)
Fin Height 0.400" (10.16mm)
Power Dissipation @ Temperature Rise 2.0W @ 45°C
Thermal Resistance @ Forced Air Flow 8.00°C/W @ 400 LFM
Material Aluminum
Material Finish Black Anodized
Base Product Number 231-69P
Standard Package 5,000
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8473.30.5100
Win Source Part Number 1350069-231-69PABE-15V
Ultra Librarian 3D Model Ultra Librarian 231-69PABE-15V CAD Model

Description

The 231-69PABE-15V is a board level, vertical heat sink from Wakefield-Vette's 231 series.

  • Shape: Rectangular, Fin-Shaped
  • Material: Aluminum
  • Package: Box
  • Length: 0.690" (17.53mm)
  • Width: 0.835" (21.21mm)
  • Designed For: TO-220 Packages
  • Attachment: Bolt-On and Board Mounts
  • Power Dissipation: 2.0W @ 45°C
  • Thermal Resistance: 8.00°C/W @ 400 LFM
  • Finish: Black Anodized
  • Fin Height: 0.400" (10.16mm)
  • Temperature Range: -40°C to 150°C
