BT158W-1200TQ WeEn Semiconductors
Same model may have multiple batches, images only for reference.

BT158W-1200TQ

Part No BT158W-1200TQ
Manufacturer WeEn Semiconductors
Catalog SCRs - Single
Description BT158W-1200TQ TO-247
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Manufacturer WeEn Semiconductors
Packaging Tube
Voltage - Off State 1.2kV
Voltage - Gate Trigger (Vgt) (Maximum) 1V
Current - Gate Trigger (Igt) (Maximum) 70mA
Voltage - On State (Vtm) (Maximum) 1.65V
Current - On State (It (AV)) (Maximum) 80A
Current - On State (It (RMS)) (Maximum) 126A
Current - Hold (Ih) (Maximum) 200mA
Current - Off State (Maximum) 3mA
Current - Non Rep. Surge 50, 60Hz (Itsm) 1100A, 1210A
SCR Type Standard Recovery
Temperature Range - Operating 150°C
Mounting Style Through Hole
Manufacturer Package TO-247-3
Supplier Device Package TO-247-3
Manufacturer Pack Quantity 240
Popularity Medium
Supply and Demand Status Balance
Win Source Part Number 806224-BT158W-1200TQ
Ultra Librarian 3D Model Ultra Librarian BT158W-1200TQ CAD Model

Description

The BT158W-1200TQ from WeEn Semiconductors is a standard recovery SCR type device with a voltage-off state of 1.2kV.

  • Current-on State: 126A (maximum)
  • Current-non rep. surge 50, 60Hz (Itsm): 1100A, 1210A
  • Voltage-gate trigger (Vgt) (maximum): 1V
  • Package: TO-247-3
  • Mounting Style: Through-Hole
  • Current-gate trigger (Igt) (maximum): 70mA
  • Current-hold (Ih) (maximum): 200mA
  • Voltage-on state (Vtm) (maximum): 1.65V
  • Current-off state (maximum): 3mA
  • Operating Temperature Range: 150°C
