1473560000 Weidmüller
Same model may have multiple batches, images only for reference.

1473560000

Part No 1473560000
Manufacturer Weidmuller
Catalog Terminal Blocks
Description PCB TERMINAL 5.00MM
Datasheet
1473560000 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Win Source Part Number WS1309675-1473560000
Manufacturer Weidmüller
Category Connectors, Interconnects > Terminal Blocks > Wire to Board
Part Status Active
Pitch 0.197" (5.00mm)
Mating Orientation Vertical with Board
Current 12 A
Mounting Type Surface Mount
Wire Termination Screwless - Push Button Clamp
Color Black
Ultra Librarian 3D Model Ultra Librarian 1473560000 CAD Model

Description

The innovative quick connector - simple, safe and economical:
PCB terminals with spring connection and direct PUSH IN technology. A milestone in connection technology. Amazingly simple and simply amazing in practice:
• Connect and easily detach solid wires or wires with wire-end ferrules without using tools
• Processed automatically in the reflow or vapour phase
• Potentials and clamping points marked clearly by coloured push buttons
