Same model may have multiple batches, images only for reference.

744042001

Name: 744042001
Brand: Wurth Electronics Inc
SKU: 802442
Availability: InStock
Rating: 4.84 (5 reviews)

Get a Quote

Part No	744042001
Manufacturer	Wurth Electronics Inc
Catalog	Fixed Inductors
Description	FIXED IND 1UH 2.7A 30 MOHM SMD / POWER-CHOKE WE-TPC
Datasheet	744042001 Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Manufacturer	Würth Elektronik
Packaging	Reel
Type	Wirewound
Material - Core	Ferrite
Inductance	1μH
Tolerance	±30%
Current Rating (Amps)	2.7A
Current - Saturation	2.6A
Shielding	Shielded
DC Resistance (DCR)	30mOhm Max
Frequency - Self Resonant	177MHz
Temperature Range - Operating	-40°C ~ 125°C
Inductance Frequency - Test	100kHz
Mounting Style	SMD
Manufacturer Package	1919 (4848 Metric)
Dimension	0.189" L x 0.189" W (4.80mm x 4.80mm)
Height - Seated (Maximum)	0.079" (2.00mm)
Manufacturer Pack Quantity	800
MSL Level	1 (Unlimited)
Popularity	High
Supply and Demand Status	Balance
Win Source Part Number	802442-744042001
Ultra Librarian 3D Model	Ultra Librarian 744042001 CAD Model

Alternative Products

Description

The 802442-744042001 from Würth Elektronik is a shielded, surface-mount wirewound inductor.

Inductance: 1μH
Tolerance: ±30%
Core Material: Ferrite
DC Resistance (DCR): 30mOhm max
Saturation Current: 2.6A
Self-Resonant Frequency: 177MHz
Package: 1919 (4848 metric)
Height: 0.079" (2.00mm)
Operating Temperature Range: -40°C to 125°C
