The 744045471 is a WE-HCFA high current inductor from Wurth Electronics. This inductor is designed for high current applications and features a flat wire construction for low DC resistance and high efficiency.

Applications:

• DC-DC converters
• Voltage regulators in high-current power supplies
• Filtering in power amplifiers
• Automotive electronics
• Industrial power systems

Features:

• High current capability
• Low DC resistance (DCR) due to flat wire construction
• Shielded construction for reduced EMI
• Compact size for space-constrained applications
• RoHS compliant

Benefits:

• Improved efficiency in power conversion
• Reduced power loss and heat generation
• Minimized electromagnetic interference
• Smaller and lighter power supply designs
• Compliant with environmental regulations

Additional Details:

The 744045471 utilizes a ferrite core material to achieve high saturation current and stable performance over temperature. Its flat wire construction allows for a larger conductor cross-section, which lowers the DC resistance and improves current handling capability. The shielding helps to contain electromagnetic emissions, ensuring compliance with EMC standards. Detailed specifications, including inductance value, saturation current, and DCR, can be found in the Wurth Electronics datasheet for this part number.

The high current capability and low DCR make this inductor suitable for applications where efficiency is critical. The compact size allows for integration into densely populated circuit boards. The shielded construction reduces the risk of interference with other components. This inductor is commonly used in power supplies for servers, industrial equipment, and automotive systems. Its robust design ensures reliable performance in demanding environments.
