744871470 Wurth Electronics Inc – Price, Stock & Datasheet
Same model may have multiple batches, images only for reference.

744871470

Part No 744871470
Manufacturer Wurth Electronics Inc
Catalog Arrays, Signal Transformers
Description Shielded 2 Coil Inductor Array 94 µH Inductance - Connected in Series 23.5 µH Inductance - Connected in Parallel 180mOhm Max DC Resistance (DCR) - Parallel 1.1 A Nonstandard
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Manufacturer Würth Elektronik
Series WE-DD
Packaging Reel - TR
Number of Coils 2
Inductance - Connected In Parallel 23.5 µH
Inductance - Connected In Series 94 µH
Tolerance ±20%
Current Rating - Parallel 1.1 A
Current Rating - Series 550 mA
Current Saturation - Parallel 2.4 A
Current Saturation - Series 1.2 A
DC Resistance (DCR) - Parallel 180mOhm Max
Shielding Shielded
Temperature Range - Operating -40°C ~ 125°C
Mounting Type Surface Mount
Package / Case Nonstandard
Size / Dimension 0.492" L x 0.492" W (12.50mm x 12.50mm)
Height 0.256" (6.50mm)
RoHS Status ROHS3 Compliant
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8504.50.4000
Win Source Part Number 1478941-744871470
Ultra Librarian 3D Model Ultra Librarian 744871470 CAD Model
