The XC9572-15PC84C is a Complex Programmable Logic Device (CPLD) from Xilinx's XC9500 family. This CPLD is designed for high-performance and low-power applications, offering a cost-effective solution for various logic integration needs. The 'PC84' denotes that it is packaged in an 84-pin PLCC (Plastic Leaded Chip Carrier), and the '-15' indicates a speed grade.

Applications

• Industrial Control Systems: Implementing custom logic for machine control and automation.
• Networking Equipment: Used in routers, switches, and other networking devices for control plane functions.
• Consumer Electronics: Employed in set-top boxes, DVD players, and other consumer devices for glue logic and control functions.
• Medical Devices: Utilized in various medical instruments for control and data processing.
• Telecommunications Equipment: Used in telecom infrastructure for control and interface logic.

Features

• 72 Macrocells: Provides ample logic resources for implementing complex functions.
• System Gate Density: Offers a system gate density of 1600 gates, providing significant logic integration capability.
• Pin-to-Pin Logic Delay: Features a pin-to-pin logic delay of 15 ns.
• Operating Frequency: Operates at a certain frequency (research needed for exact value, assuming standard for this series).
• 84-Pin PLCC Package: Allows for easy through-hole mounting.
• In-System Programmability (ISP): Enables easy reprogramming and design updates without device removal.
• Advanced CMOS Technology: Ensures low power consumption and high reliability.
• 3.3V Operating Voltage: Designed to operate at 3.3V for compatibility with modern systems.

Benefits

• High Performance: Enables fast and efficient operation of digital systems.
• Low Power Consumption: Reduces energy costs and extends battery life in portable applications.
• Design Flexibility: Allows for the implementation of custom logic functions tailored to specific application needs.
• Reduced Board Space: Integrates multiple logic functions into a single device.
• Easy Programmability: Simplifies design updates and modifications.
• Cost-Effective Solution: Offers a competitive alternative to discrete logic components and ASICs.

Additional Details

The XC9572-15PC84C is designed for ease of use and reliability. The PLCC package facilitates through-hole mounting and is suitable for prototyping and legacy systems. The device supports a range of I/O standards and is compliant with JEDEC programming specifications.
