Same model may have multiple batches, images only for reference.

B0540WS

Name: B0540WS
Brand: Yangzhou yangjie electronic co., ltd
SKU: 567764
Availability: InStock
Rating: 4.91 (5 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	B0540WS
Manufacturer	Yangzhou yangjie electronic co., ltd
Catalog	Diodes, Rectifiers - Single
Description	DIODE SCHOTTKY 40V 500MA SOD323
Datasheet	B0540WS Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Discrete Semiconductor Products - Diodes - Rectifiers - Single Diodes
Mfr	Yangzhou yangjie electronic co., ltd
Package	Tape & Reel
Product Status	Active
Technology	Schottky
Voltage - DC Reverse (Vr) (Max)	40 V
Current - Average Rectified (Io)	500mA
Voltage - Forward (Vf) (Max) @ If	550 mV @ 500 mA
Speed	Fast Recovery =< 500ns, > 200mA (Io)
Current - Reverse Leakage @ Vr	80 µA @ 40 V
Capacitance @ Vr, F	30pF @ 4V, 1MHz
Mounting Type	Surface Mount
Package / Case	SC-76, SOD-323
Supplier Device Package	SOD-323
Operating Temperature - Junction	-55°C ~ 125°C
Standard Package	3,000 pcs
MSL Level	1 (Unlimited)
REACH Status	REACH Unaffected
ECCN	EAR99
HTSUS	8541.10.0070
Win Source Part Number	567764-B0540WS
Ultra Librarian 3D Model	Ultra Librarian B0540WS CAD Model

Alternative Products

Description

The 567764-B0540WS is a fast recovery Schottky diode designed for use in rectifier applications manufactured by Yangzhou yangjie electronic co., ltd.

Maximum DC Reverse Voltage: 40V.
Average Rectified Current: 500mA.
Forward Voltage: 550mV @ 500mA.
Reverse Leakage Current: 80μA @ 40V.
Capacitance: 30pF @ 4V and 1MHz.
Operating Temperature Range: -55°C to 125°C.
Package Type: SC-76, SOD-323.
Product Status: Active.
