Same model may have multiple batches, images only for reference.

BAS16WS

Name: BAS16WS
Brand: Yangzhou yangjie electronic co., ltd
SKU: 568659
Availability: InStock
Rating: 4.85 (5 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	BAS16WS
Manufacturer	Yangzhou yangjie electronic co., ltd
Catalog	Diodes, Rectifiers - Single
Description	DIODE GEN PURP 75V 200MA SOD323
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Discrete Semiconductor Products - Diodes - Rectifiers - Single Diodes
Mfr	Yangzhou yangjie electronic co., ltd
Package	Tape & Reel
Product Status	Active
Technology	Standard
Voltage - DC Reverse (Vr) (Max)	75 V
Current - Average Rectified (Io)	200mA
Voltage - Forward (Vf) (Max) @ If	1.25 V @ 150 mA
Speed	Small Signal =< 200mA (Io), Any Speed
Reverse Recovery Time (trr)	6 ns
Current - Reverse Leakage @ Vr	1 µA @ 75 V
Capacitance @ Vr, F	4pF @ 0V, 1MHz
Mounting Type	Surface Mount
Package / Case	SC-76, SOD-323
Supplier Device Package	SOD-323
Operating Temperature - Junction	-55°C ~ 150°C
Base Product Number	BAS16
Standard Package	3,000 pcs
MSL Level	1 (Unlimited)
REACH Status	REACH Unaffected
ECCN	EAR99
HTSUS	8541.10.0070
Win Source Part Number	568659-BAS16WS
Ultra Librarian 3D Model	Ultra Librarian BAS16WS CAD Model

Alternative Products

Description

The 568659-BAS16WS is a single rectifier diode designed for use in discrete semiconductor products. It is part of the rectifier diode series and is manufactured by Yangzhou yangjie electronic co., ltd.

Package: SC-76, SOD-323
Maximum Average Rectified Current: 200mA
Forward Voltage: 1.25 V @ 150 mA
Reverse Recovery Time: 6 ns
Reverse Leakage Current: 1 μA @ 75 V
Capacitance: 4pF @ 0V, 1MHz
Operating Temperature Range: -55°C to 150°C
Package: Tape and reel with 3,000 pieces
ECCN: EAR99
