The MMBT3904DW is a dual NPN bipolar junction transistor (BJT) from Yea Shin Technology Co., Ltd. Housed in a small SOT-363 package, this device is designed for general-purpose amplification and switching applications where space is at a premium.

Applications:

• General Purpose Amplification
• Switching Circuits
• Driver Stages
• Digital Circuits

Features:

• Dual NPN Transistor
• Collector-Emitter Voltage (VCEO): 40V
• Collector Current (IC): 200mA
• High Transition Frequency (fT): 300 MHz (typical)
• Low Saturation Voltage
• Small SOT-363 Package

Benefits:

• Saves board space by incorporating two transistors in a single package
• Suitable for a wide range of applications due to its general-purpose characteristics
• Fast switching speed due to high transition frequency
• Low power dissipation
• Simplified circuit design

Additional Details:

The MMBT3904DW's characteristics make it suitable for various small-signal applications. Its low saturation voltage minimizes power loss during switching. The high transition frequency enables its use in high-speed circuits. The compact SOT-363 package makes it ideal for applications where board space is limited. It's commonly used in portable devices, instrumentation, and other space-constrained applications. The device's robust construction ensures reliable performance. The MMBT3904DW is a cost-effective solution for applications requiring multiple transistors. It offers a balance of performance, size, and cost, making it a popular choice for designers. When using the MMBT3904DW, it's important to consider the thermal characteristics to ensure the device operates within its safe operating area. Using current limiting resistors is also recommended to prevent damage to the transistors.
