DW025ACL-M Lineage Power Corporation
Same model may have multiple batches, images only for reference.

DW025ACL-M

Part No DW025ACL-M
Manufacturer ABB Embedded Power
Catalog Power Supplies Board Mount DCDC Converters
Description DC DC CONVERTER 5V +/-15V 25W
Datasheet
DW025ACL-M Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Power Supplies - Board Mount - DC DC Converters
Mfr ABB Embedded Power
Series DW025 (25W)
Package Bulk
Product Status Obsolete
Type Isolated Module
Number of Outputs 3
Voltage - Input (Min) 36V
Voltage - Input (Max) 75V
Voltage - Output 1 5V
Voltage - Output 2 15V
Voltage - Output 3 -15V
Current - Output (Max) 5A, 830mA, 830mA
Power (Watts) 25 W
Voltage - Isolation 500 V
Applications ITE (Commercial)
Features Remote On/Off, OCP, OVP
Temperature Range - Operating -40°C ~ 100°C
Efficiency 83%
Mounting Type Through Hole
Package / Case 9-DIP Module
Size / Dimension 2.80" L x 2.40" W x 0.50" H (71.1mm x 61.0mm x 12.7mm)
Control Features Enable, Active High
Standard Package 30 pcs
MSL Level Not Applicable
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8504.40.9580
Win Source Part Number 587772-DW025ACL-M
Ultra Librarian 3D Model Ultra Librarian DW025ACL-M CAD Model

Description

The DW025ACL-M 587772-DW025ACL-M is an isolated module designed for power supplies in board mount DC-DC converters.

  • Size: 2.80" L x 2.40" W x 0.50" H (71.1mm x 61.0mm x 12.7mm)
  • Power Output: 25W
  • Outputs: Three Outputs
  • Output 1: 5V @ 5A
  • Output 2: 15V @ 830mA
  • Output 3: -15V @ 830mA
  • Control Features: Remote On/Off, Overcurrent Protection (OCP), Overvoltage Protection (OVP)
  • Mounting: Through-Hole
  • Package: 9-DIP
  • Operating Temperature: -40°C to 100°C
  • Efficiency: 83%
  • Series: DW025 (25W)
  • Application: ITE (Commercial)
  • Status: Obsolete
  • Standard Package: 30 pcs
