A3966SLB Real Image A3966SLB real image17053
Same model may have multiple batches, images only for reference.
A3966SLB Real Image A3966SLB real image17053
A3966SLB Real Image A3966SLB real image17053
Same model may have multiple batches, images only for reference.

A3966SLB

Part No A3966SLB
Manufacturer Allegro MicroSystems, LLC
Catalog PMIC - Motor Drivers, Controllers
Description Dual Full Bridge Motor Driver 16-Pin SOIC W Tube / DUAL FULL-BRIDGE PWM MOTOR DRIVER | IC MTRDRV BIPLR 4.75-5.5V 16SOIC
Datasheet
A3966SLB Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Allegro MicroSystems, LLC
Packaging Tube
Status Obsolete
Motor Type - Stepper Bipolar
Function Driver - Fully Integrated, Control and Power Stage
Output Configuration Half Bridge (4)
Interface Parallel
Technology Bipolar
Applications General Purpose
Output Current 650mA
Supply Voltage (V) 4.75V ~ 5.5V
Load Voltage (V) 4.75V ~ 30V
Temperature Range - Operating -20°C ~ 150°C
Mounting Style SMD
Manufacturer Package 16-PowerSOIC
Supplier Device Package 16-SOIC
Family Part Number A3966
Manufacturer Pack Quantity 47
MSL Level 1 (Unlimited)
Win Source Part Number 1134601-A3966SLB
Manufacturer Homepage www.allegromicro.com
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Family Name A3966SLB
Introduction Date October 28, 2003
ECCN EAR99
Halogen Free Compliant
Estimated EOL Date Obsolete / End of life
Ultra Librarian 3D Model Ultra Librarian A3966SLB CAD Model

Description

The A3966SLB from Allegro MicroSystems is a fully integrated driver with control and power stage designed for general purpose applications.

  • Technology: Bipolar technology
  • Interface: Parallel interface
  • Output Configuration: Half bridge
  • Outputs: Four outputs capable of delivering up to 650mA of output current
  • Motor Type: Bipolar
  • Package: 16-SOIC package
  • Status: Obsolete
  • Operating Temperature Range: From -20°C to 150°C
  • Alternative Parts: BD6380EFV-E2, BU64297GWZ-TR, BD6211HFP-E2, and BD6211HFP-TR
