ACS70331EESATR-005B3 Real Image ACS70331EESATR-005B3 Real Image
Same model may have multiple batches, images only for reference.
ACS70331EESATR-005B3 Real Image ACS70331EESATR-005B3 Real Image
ACS70331EESATR-005B3 Real Image ACS70331EESATR-005B3 Real Image
Same model may have multiple batches, images only for reference.

ACS70331EESATR-005B3

Part No ACS70331EESATR-005B3
Manufacturer Allegro MicroSystems, LLC
Catalog Current Transducers
Description HIGH SENSITIVITY, 1 MHZ, GMR-BAS  /  Current Sensor ±5A 1 Channel Hall Effect, Open Loop Bidirectional 12-PowerWFQFN
Datasheet
ACS70331EESATR-005B3 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Sensors, Transducers>Current Sensors
Mfr Allegro MicroSystems
Series ACS70331
Package Tape & Reel
For Measuring AC/DC
Sensor Type Hall Effect, Open Loop
Current - Sensing ±5A
Number of Channels 1
Output Voltage
Sensitivity 200mv/A
Frequency DC ~ 1MHz
Linearity ±0.2%
Accuracy ±2%
Voltage - Supply 3V ~ 4.5V
Response Time 535ns
Current - Supply (Max) 6mA
Temperature Range - Operating -40°C ~ 85°C
Polarization Bidirectional
Mounting SMD (SMT)
Package / Case 12-PowerWFQFN
Supplier Device Package 12-QFN (3x3)
Base Product Number ACS703
MSL Level 2 (1 Year)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8542.39.0001
Other Names 620-1887-6,620-1887-1,620-1887-2
Standard Package 1,500
Win Source Part Number 982523-ACS70331EESATR-005B3
Ultra Librarian 3D Model Ultra Librarian ACS70331EESATR-005B3 CAD Model

Description

The Allegro MicroSystems ACS70331EESATR-005B3 is a Hall Effect current sensor that features a bidirectional polarization.

  • Manufacturer: Allegro MicroSystems
  • Polarization: Bidirectional
  • Maximum Current Supply: 6mA
  • Sensitivity: 200mV/A
  • Application: AC/DC current measurement
  • Maximum Current Sensing: ±5A
  • Linearity: ±0.2%
  • Accuracy: ±2%
  • Mounting Technology: SMD (SMT)
  • Package/Case: 12-PowerWFQFN
  • Packaging: Tape and Reel
  • Units Per Package: 1500
  • Operating Temperature Range: -40°C to 85°C
  • RoHS Compliant: No
