ACS758ECB-200B-PFF-T Real Image ACS758ECB-200B-PFF-T real image17072 ACS758ECB-200B-PFF-T real image17073 ACS758ECB-200B-PFF-T Real Image
Same model may have multiple batches, images only for reference.
ACS758ECB-200B-PFF-T Real Image ACS758ECB-200B-PFF-T real image17072 ACS758ECB-200B-PFF-T real image17073 ACS758ECB-200B-PFF-T Real Image
ACS758ECB-200B-PFF-T Real Image ACS758ECB-200B-PFF-T real image17072 ACS758ECB-200B-PFF-T real image17073 ACS758ECB-200B-PFF-T Real Image
Same model may have multiple batches, images only for reference.

ACS758ECB-200B-PFF-T

Part No ACS758ECB-200B-PFF-T
Manufacturer Allegro MicroSystems, LLC
Catalog Current Sense Transformers
Description Thermally Enhanced, Fully Integrated, Hall Effect-Based Linear Current Sensor IC with 100 μΩ Current Conductor | SENSOR CURRENT HALL 200A AC/DC / Open Loop Current Sensor AC/DC Current 5V Automotive 5-Pin Case CB-PFF Tube
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Sensors, Transducers
Manufacturer Allegro MicroSystems, LLC
Packaging Tube
For Measuring AC/DC
Sensor Type Hall Effect, Open Loop
Current - Sensing 200A
Output Ratiometric, Voltage
Sensitivity 10mV/A
Frequency DC ~ 120kHz
Linearity ±1%
Accuracy ±1.2%
Supply Voltage (V) 3V ~ 5.5V
Response Time 4μs
Maximum Supply Current 13.5mA
Temperature Range - Operating -40°C ~ 85°C
Polarization Bidirectional
Mounting Style Through Hole
Manufacturer Package 5-CB Formed Leads, PFF
Supplier Device Package 5-CB Module
Manufacturer Pack Quantity 34
MSL Level 1 (Unlimited)
Win Source Part Number 1135518-ACS758ECB-200B-PFF-T
Manufacturer Homepage www.allegromicro.com
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Application Field Used in Sensing & Instrumentation, Motor Drive & Control, Power Management, Automotive
Family Name ACS758ECB
Introduction Date March 26, 2009
ECCN EAR99
Country of Origin Philippines
Halogen Free Compliant
Estimated EOL Date 2025
Ultra Librarian 3D Model Ultra Librarian ACS758ECB-200B-PFF-T CAD Model

Description

The Allegro MicroSystems ACS758ECB-200B-PFF-T from is a hall-effect sensor that comes in a 5-CB formed leads, PFF package.

  • Polarization: Bidirectional
  • Sensitivity: 10mV/A
  • Output: Ratiometric Voltage
  • Current Sensing Range: 200A
  • Operating Temperature Range: -40°C to 85°C
  • Family: ACS758ECB
  • Applications: Sensing and Transducer
  • Popularity: High
  • Supply and Demand Status: Balance
  • Manufacturer Homepage: www.allegromicro.com
