CST206-3T

Part No CST206-3T
Manufacturer Triad Magnetics
Catalog Current Sense Transformers
Description CURR SENSE XFMR 70A T/H
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Frequency Range 20kHz ~ 200kHz
Type Non-Invasive (Solid Core)
Current Rating (Amps) 70 A
Inductance 130 mH
ET (Volt-Time) 6000VµS
Current Ratio 300:1
DC Resistance (DCR) 12.4Ohm Max
Mounting Type Through Hole
Size / Dimension 1.075" L x 0.400" W (27.31mm x 10.16mm)
Height - Seated (Max) 1.225" (31.12mm)
Termination Style PC Pin
Package Bulk
Supply and Demand Status Shortage
Win Source Part Number 1545060-CST206-3T
Ultra Librarian 3D Model Ultra Librarian CST206-3T CAD Model
