AO3401A

Part No AO3401A
Manufacturer Alpha & Omega Semiconductor Inc.
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET P-CH 30V 4A SOT23
Datasheet
Sample
Rohs State Need to verify
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Alpha & Omega Semiconductor Inc.
Packaging Reel - TR
Status Active
Polarity P-Channel
Technology MOSFET
Drain-Source Breakdown Voltage 30V
Continuous Drain Current at 25°C 4A (Ta)
Drive Voltage (Max Rds On, Min Rds On) 2.5V, 10V
Gate-Source Threshold Voltage 1.3V @ 250μA
Max Gate Charge 12.2nC @ 4.5V
Max Input Capacitance 1200pF @ 15V
Maximum Gate-Source Voltage ±12V
Power Dissipation (Max) 1.4W (Ta)
Maximum Rds On at Id,Vgs 44 mOhm @ 4.3A, 10V
Temperature Range - Operating -55°C to 150°C (TJ)
Mounting SMD (SMT)
Case / Package SOT-23-3L
Dimension TO-236-3, SC-59, SOT-23-3
Win Source Part Number 009718-AO3401A
Family Name AO3401A
Introduction Date April 10, 2007
ECCN EAR99
Country of Origin China
Halogen Free Compliant
Estimated EOL Date 2022
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Ultra Librarian 3D Model Ultra Librarian AO3401A CAD Model

Description

AO3401A from Alpha & Omega Semiconductor Inc. is a MOSFET device used by engineers in compact switching and signal-control designs where board space, cost efficiency, and dependable sourcing all matter. It is commonly considered for portable electronics, power-path control, load switching, DC-DC support circuits, and general embedded hardware designs that require a small-footprint transistor solution. Its market value is tied to broad design relevance and the strong ecosystem around standard MOSFET selection, making it useful for both new builds and maintenance sourcing. Because the listed lifecycle status is unknown, design teams should treat long-term availability cautiously and confirm current production status directly with the manufacturer or authorized distribution before committing to volume programs. RoHS compliance information is not available in the provided data, so environmental compliance should also be verified through the latest datasheet, declaration, or manufacturer statement before procurement for regulated products.
