AO6601 Real Image AO6601 Real Image
Same model may have multiple batches, images only for reference.
AO6601 Real Image AO6601 Real Image
AO6601 Real Image AO6601 Real Image
Same model may have multiple batches, images only for reference.

AO6601

Part No AO6601
Manufacturer Alpha & Omega Semiconductor Inc.
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET N/P-CH 30V 6-TSOP
Datasheet
AO6601 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Alpha & Omega Semiconductor Inc.
Packaging Reel - TR
Status Active
FET Type N and P-Channel Complementary
FET Feature Logic Level Gate
Drain-Source Breakdown Voltage 30V
Continuous Drain Current at 25°C 3.4A, 2.3A
Maximum Rds On at Id,Vgs 60 mOhm @ 3.4A, 10V
Gate-Source Threshold Voltage 1.5V @ 250μA
Max Gate Charge 12nC @ 10V
Max Input Capacitance 285pF @ 15V
Maximum Power Dissipation 1.15W
Temperature Range - Operating -55°C to 150°C (TJ)
Mounting SMD (SMT)
Case / Package 6-TSOP
Win Source Part Number 096682-AO6601
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Family Name AO6601
Introduction Date February 25, 2008
ECCN EAR99
Country of Origin China
Halogen Free Compliant
Estimated EOL Date 2022
Ultra Librarian 3D Model Ultra Librarian AO6601 CAD Model

Description

AO6601 MOSFET Transistor

The AO6601 is a state-of-the-art MOSFET transistor offering unparalleled performance for a wide range of applications. Known for its integrated design and functionality, it is particularly suitable where high power management is needed.

Features and Benefits

  • Compact and Highly Efficient
  • Low On-Resistance
  • Fast Switching to support rapid operations
  • Low Thermal Resistance for better heat dissipation

Applications

  • Power tools
  • Industrial Automation
  • Consumer Electronics
  • High-Efficiency Power Supplies

The AO6601 provides a perfect balance between size, performance, and reliability, making it an ideal choice for power-sensitive applications.
