AO8810 Real Image AO8810 real image1857 AO8810 real image1858
Same model may have multiple batches, images only for reference.
AO8810 Real Image AO8810 real image1857 AO8810 real image1858
AO8810 Real Image AO8810 real image1857 AO8810 real image1858
Same model may have multiple batches, images only for reference.

AO8810

Part No AO8810
Manufacturer Alpha & Omega Semiconductor Inc.
Catalog Transistors - FETs, MOSFETs - RF
Description Trans MOSFET N-CH 20V 7A 8-Pin TSSOP / MOSFET 2N-CH 20V 7A 8-TSSOP
Datasheet
AO8810 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Alpha & Omega Semiconductor Inc.
Packaging Reel - TR
Status Active
FET Type 2 N-Channel (Dual) Common Drain
FET Feature Logic Level Gate
Drain-Source Breakdown Voltage 20V
Continuous Drain Current at 25°C 7A
Maximum Rds On at Id,Vgs 20 mOhm @ 7A, 4.5V
Gate-Source Threshold Voltage 1.1V @ 250μA
Max Gate Charge 14nC @ 4.5V
Max Input Capacitance 1295pF @ 10V
Maximum Power Dissipation 1.5W
Temperature Range - Operating -55°C to 150°C (TJ)
Mounting SMD (SMT)
Case / Package 8-TSSOP
Win Source Part Number 096937-AO8810
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Family Name AO8810
Introduction Date February 21, 2008
ECCN EAR99
Country of Origin China
Halogen Free Compliant
Estimated EOL Date 2022
Ultra Librarian 3D Model Ultra Librarian AO8810 CAD Model

Description

AO8810 MOSFET Overview

The AO8810 is engineered to offer exceptional efficiency in power management applications. Its high-efficiency characteristics make it a leading choice among power electronics professionals.

Features and Benefits

  • Enhanced thermal performance
  • Broad voltage range for flexible usage
  • Minimal gate charge to enhance efficiency
  • RoHS compliant package

Applications

  • Load switch
  • Motor drive control
  • Telecommunication equipment
  • Energy-efficient lighting

Additional details: With its reliable and efficient design, the AO8810 is perfect for enhancing the performance of compact and power-sensitive applications.
