AOD417 Alpha & Omega Semiconductor Inc. AOD417 real image1864
Same model may have multiple batches, images only for reference.
AOD417 Alpha & Omega Semiconductor Inc. AOD417 real image1864
AOD417 Alpha & Omega Semiconductor Inc. AOD417 real image1864
Same model may have multiple batches, images only for reference.

AOD417

Part No AOD417
Manufacturer Alpha & Omega Semiconductor Inc.
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET P-CH 30V 25A TO252 / Trans MOSFET P-CH 30V 25A 3-Pin(2+Tab) DPAK
Datasheet
AOD417 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Alpha & Omega Semiconductor Inc.
Packaging Reel - TR
Status Active
Polarity P-Channel
Technology MOSFET
Drain-Source Breakdown Voltage 30V
Continuous Drain Current at 25°C 25A (Ta)
Drive Voltage (Max Rds On, Min Rds On) 4.5V, 10V
Gate-Source Threshold Voltage 3V @ 250μA
Max Gate Charge 16.2nC @ 10V
Max Input Capacitance 920pF @ 15V
Maximum Gate-Source Voltage ±20V
Power Dissipation (Max) 2.5W (Ta), 50W (Tc)
Maximum Rds On at Id,Vgs 34 mOhm @ 20A, 10V
Temperature Range - Operating -55°C to 175°C (TJ)
Mounting SMD (SMT)
Case / Package TO-252, (D-Pak)
Dimension TO-252-3, DPak (2 Leads + Tab), SC-63
Win Source Part Number 009799-AOD417
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Family Name AOD417
Introduction Date October 16, 2006
ECCN EAR99
Country of Origin China
Halogen Free Compliant
Estimated EOL Date 2025
Ultra Librarian 3D Model Ultra Librarian AOD417 CAD Model

Description

Product Overview

The AOD417 MOSFET is engineered for top-notch efficiency and broad usability in electronic projects. It features cutting-edge technology to support a diverse range of high-power applications.

Features

  • High Drain Current Capability
  • Low Gate Charge
  • Advanced Junction Technology
  • Comprehensive Surge Protection

Benefits

  • Lower switching losses
  • Higher power density
  • Minimal heat dissipation
  • Consistent operation in diverse environments

Applications

  • Power Inverters
  • Telecommunications Equipment
  • Uninterruptible Power Supplies (UPS)
  • Lighting Systems
