AOD4S60 Alpha & Omega Semiconductor Inc. AOD4S60 Real Image AOD4S60 real image AOD4S60 real image 2
Same model may have multiple batches, images only for reference.
AOD4S60 Alpha & Omega Semiconductor Inc. AOD4S60 Real Image AOD4S60 real image AOD4S60 real image 2
AOD4S60 Alpha & Omega Semiconductor Inc. AOD4S60 Real Image AOD4S60 real image AOD4S60 real image 2
Same model may have multiple batches, images only for reference.

AOD4S60

Part No AOD4S60
Manufacturer Alpha & Omega Semiconductor Inc.
Catalog Transistors - FETs, MOSFETs - RF
Description Trans MOSFET N-CH 600V 4A 3-Pin(2+Tab) DPAK / MOSFET N-CH 600V 4A TO252
Datasheet
AOD4S60 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Alpha & Omega Semiconductor Inc.
Packaging Reel - TR
Status Active
Polarity N-Channel
Technology MOSFET
Drain-Source Breakdown Voltage 600V
Continuous Drain Current at 25°C 4A (Tc)
Drive Voltage (Max Rds On, Min Rds On) 10V
Gate-Source Threshold Voltage 4.1V @ 250μA
Max Gate Charge 6nC @ 10V
Max Input Capacitance 263pF @ 100V
Maximum Gate-Source Voltage ±30V
Power Dissipation (Max) 56.8W (Tc)
Maximum Rds On at Id,Vgs 900 mOhm @ 2A, 10V
Temperature Range - Operating -55°C to 150°C (TJ)
Mounting SMD (SMT)
Case / Package TO-252, (D-Pak)
Dimension TO-252-3, DPak (2 Leads + Tab), SC-63
Win Source Part Number 1016930-AOD4S60
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Family Name AOD4S60
ECCN EAR99
Country of Origin China
Halogen Free Compliant
Estimated EOL Date 2026
Ultra Librarian 3D Model Ultra Librarian AOD4S60 CAD Model

Description

The AOD4S60 is a MOSFET transistor manufactured by Alpha & Omega Semiconductor Inc.

  • Supply and Demand Status: Balanced
  • Polarity: N-channel
  • Maximum Drain-Source Breakdown Voltage: 600V
  • Continuous Drain Current @ 25°C: 4A
  • Gate-Source Threshold Voltage: Low
  • Input Capacitance: Low
