Same model may have multiple batches, images only for reference.
AON2411 Real Image
Same model may have multiple batches, images only for reference.

AON2411

Part No AON2411
Manufacturer Alpha & Omega Semiconductor Inc.
Catalog Transistors - FETs, MOSFETs - RF
Description Trans MOSFET P-CH 12V 20A DFN-C T/R / MOSFET P-CH 12V 20A 8DFN
Datasheet
AON2411 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Alpha & Omega Semiconductor Inc.
Packaging Reel - TR
Status Active
Polarity P-Channel
Technology MOSFET
Drain-Source Breakdown Voltage 12V
Continuous Drain Current at 25°C 20A (Ta)
Drive Voltage (Max Rds On, Min Rds On) 1.8V, 4.5V
Gate-Source Threshold Voltage 900mV @ 250μA
Max Gate Charge 30nC @ 4.5V
Max Input Capacitance 2180pF @ 6V
Maximum Gate-Source Voltage ±8V
Power Dissipation (Max) 5W (Ta)
Maximum Rds On at Id,Vgs 8 mOhm @ 12A, 4.5V
Temperature Range - Operating -55°C to 150°C (TJ)
Mounting SMD (SMT)
Case / Package 8-DFN (2x2)
Dimension 8-PowerWDFN
Win Source Part Number 1017007-AON2411
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Family Name AON2411
Introduction Date December 09, 2013
ECCN EAR99
Country of Origin China
Halogen Free Compliant
Estimated EOL Date 2025
Ultra Librarian 3D Model Ultra Librarian AON2411 CAD Model

Description

The Alpha & Omega Semiconductor AON2411 is a P-channel MOSFET that is designed for use in discrete semiconductor products.

  • Packaging: Reel-tr
  • Mounting Technology: SMD (SMT)
  • Power Dissipation: 5W (Ta)
  • Family Name: AON2411
  • Drive Voltage: 1.8V (max Rds On) and 4.5V (min Rds On)
  • Operating Temperature: -55°C to 150°C (TJ)
  • Package Dimension: 8-PowerWDFN
  • Drain-Source Breakdown Voltage: 12V
  • Maximum Gate-Source Voltage: ±8V
  • Maximum Rds On @ Id, Vgs: 8 mOhm @ 12A, 4.5V
  • Supply and Demand Status: Balanced
