AON7405

Part No AON7405
Manufacturer Alpha & Omega Semiconductor Inc.
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET P-CH 30V 25A 8DFN
Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Alpha & Omega Semiconductor Inc.
Packaging Reel - TR
Status Active
Polarity P-Channel
Technology MOSFET
Drain-Source Breakdown Voltage 30V
Continuous Drain Current at 25°C 25A (Ta), 50A (Tc)
Drive Voltage (Max Rds On, Min Rds On) 4.5V, 10V
Gate-Source Threshold Voltage 2.8V @ 250μA
Max Gate Charge 51nC @ 10V
Max Input Capacitance 2940pF @ 15V
Maximum Gate-Source Voltage ±25V
Power Dissipation (Max) 6.25W (Ta), 83W (Tc)
Maximum Rds On at Id,Vgs 6.2 mOhm @ 20A, 10V
Temperature Range - Operating -55°C to 150°C (TJ)
Mounting SMD (SMT)
Case / Package 8-DFN-EP (3.3x3.3)
Dimension 8-PowerWDFN
Win Source Part Number 140594-AON7405
Family Name AON7405
Introduction Date February 02, 2010
ECCN EAR99
Country of Origin China
Halogen Free Compliant
Estimated EOL Date 2022
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Ultra Librarian 3D Model Ultra Librarian AON7405 CAD Model

Description

Overview

The AON7405 is a versatile N-channel MOSFET tailored for power management and high-efficiency applications. Its robust design provides optimal performance through minimized conduction losses and fast switching capabilities.

Applications

  • DC-DC converters
  • Telecommunication power supplies
  • Industrial power management

Features and Benefits

  • Low gate charge: Reduces the drive requirements and improves efficiency.
  • High power handling capability: Supports applications with demanding electrical requirements.
  • Excellent thermal performance: Ensures stability and longevity in operations.

Additional Details

Ideal for a broad range of electronic projects, the AON7405 excels in environments where efficiency and performance are critical. Its compact form factor and compatibility with automated assembly processes facilitate seamless integration into complex systems.
