AONS66920 Real Image AONS66920 real image25628 AONS66920 real image25629
Same model may have multiple batches, images only for reference.
AONS66920 Real Image AONS66920 real image25628 AONS66920 real image25629
AONS66920 Real Image AONS66920 real image25628 AONS66920 real image25629
Same model may have multiple batches, images only for reference.

AONS66920

Part No AONS66920
Manufacturer Alpha & Omega Semiconductor Inc.
Catalog Transistors - FETs, MOSFETs - RF
Datasheet
AONS66920 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Discrete Semiconductor Products>Transistors - FETs, MOSFETs - Single
Mfr Alpha & Omega Semiconductor Inc.
Series AlphaSGT™
Package Tape & Reel
FET Type N-Channel
Technology MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss) 100 V
Current - Continuous Drain (Id) @ 25°C 17.5A (Ta), 48A (Tc)
Drive Voltage (Max Rds On, Min Rds On) 4.5V, 10V
Rds On (Max) @ Id, Vgs 8.2mOhm @ 20A, 10V
Vgs(th) (Max) @ Id 2.5V @ 250µA
Gate Charge (Qg) (Max) @ Vgs 50 nC @ 10 V
Vgs (Max) ±20V
Input Capacitance (Ciss) (Max) @ Vds 2500 pF @ 50 V
Power Dissipation (Max) 5W (Ta), 56.5W (Tc)
Temperature Range - Operating -55°C ~ 150°C (TJ)
Mounting SMD (SMT)
Supplier Device Package 8-DFN (5x6)
Package / Case 8-PowerSMD, Flat Leads
Other Names 785-1843-1,785-1843-2,785-1843-6
Standard Package 3,000
MSL Level 1 (Unlimited)
ECCN EAR99
HTSUS 8541.29.0095
Win Source Part Number 1278409-AONS66920
Ultra Librarian 3D Model Ultra Librarian AONS66920 CAD Model

Description

The AONS66920 is a N-channel MOSFET from Alpha & Omega Semiconductor Inc.

  • Package: 8-PowerSMD, Flat Leads
  • Series: AlphaSGT™
  • Drain-Source Voltage: 100V
  • Continuous Drain Current: 17.5A @ 25°C
