AZ5125-01H.R7G Amazing
Same model may have multiple batches, images only for reference.

AZ5125-01H.R7G

Part No AZ5125-01H.R7G
Manufacturer Amazing
Catalog HOT - SALES and EOL Components (0 - A)
Description ESD Suppressor TVS 5V 2-Pin SOD-523 T/R
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Manufacturer Amazing
Win Source Part Number 66882-AZ5125-01H.R7G
Family Name AZ5125-01H
Introduction Date June 17, 2002
ECCN EAR99
Estimated EOL Date 2024
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Ultra Librarian 3D Model Ultra Librarian AZ5125-01H.R7G CAD Model

Description

AZ5125-01H.R7G Diode

The AZ5125-01H.R7G is an advanced variation of the AZ5125 series, providing robust performance and enhanced durability. This diode is ideal for high-stress environments.

  • Applications:
    • Industrial Power Systems
    • Renewable Energy Solutions
    • High Frequency Inverters
  • Features and Benefits:
    • Improved thermal management
    • Precision fit for automated assembly
    • High reliability in critical operations
    • Cost-effective long-term solution
  • Additional Details:
    • Part Number: AZ5125-01H.R7G
    • Enhanced lead-free finish
    • Optimized for high performance
