100B560JT500XT American Technical Ceramics 100B560JT500XT Real Image 100B560JT500XT label picture
Same model may have multiple batches, images only for reference.
100B560JT500XT American Technical Ceramics 100B560JT500XT Real Image 100B560JT500XT label picture
100B560JT500XT American Technical Ceramics 100B560JT500XT Real Image 100B560JT500XT label picture
Same model may have multiple batches, images only for reference.

100B560JT500XT

Part No 100B560JT500XT
Manufacturer American Technical Ceramics
Catalog Ceramic Capacitors
Description Cap Ceramic 56pF 500V +90±30ppm/C 5% Pad SMD 175°C Low ESR T/R / CAP CER 56PF 500V P90 1111
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Capacitors
Manufacturer American Technical Ceramics
Packaging Reel - TR
Status Active
Capacitance 56pF
Tolerance ±5%
Voltage Rating 500V
Temperature Coefficient P90
Temperature Range - Operating -55°C to 175°C
Features High Q, Low Loss, Low ESL
Applications RF, Microwave, High Frequency
Mounting Surface Mount, MLCC
Dimension 0.110" L x 0.110" W (2.79mm x 2.79mm)
Thickness (Max) 0.102" (2.59mm)
Win Source Part Number 1000794-100B560JT500XT
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Family Name ATC 100 B
Introduction Date March 31, 2000
ECCN EAR99
Country of Origin United States of America
Halogen Free Compliant
Estimated EOL Date 2029
Ultra Librarian 3D Model Ultra Librarian 100B560JT500XT CAD Model

Description

The ATC 100 B 56pF 500V MLCC is a high-quality, low-loss, low-ESL capacitor manufactured by American Technical Ceramics.

  • Capacitance: 56pF
  • Tolerance: ±5%
  • Voltage Rating: 500V
  • Halogen-Free: Yes
  • Packaging: Reel - TR
  • Dimensions: 0.110" L x 0.110" W (2.79mm x 2.79mm)
  • Estimated EOL Date: 2029
