AD5246BKSZ10-RL7 Digital Potentiometer by Analog Devices Inc.

The AD5246BKSZ10-RL7 is a high-performance digital potentiometer designed and manufactured by Analog Devices Inc., a leader in precision high-performance integrated circuits. This digital potentiometer, or digipot, offers a compact and precise solution for adjusting and controlling resistance values in electronic circuits programmatically, without the need for manual potentiometer adjustments.

This particular model features a 10 kΩ end-to-end resistance value, providing a wide range of adjustable resistance for various applications. The compact surface-mount package makes it an ideal choice for space-constrained designs. With its single-channel configuration, the AD5246BKSZ10-RL7 allows for fine-tuning and calibration through a simple two-wire I2C-compatible digital interface, which facilitates easy integration into a wide array of digital systems.

Key features of the AD5246BKSZ10-RL7 include:

• 10 kΩ end-to-end resistance
• 256-position resolution, offering fine incremental adjustments
• Non-volatile memory, which retains the last programmed resistance value even after power-off
• Low temperature coefficient, ensuring stable performance across varying temperatures
• Wide operating voltage range, accommodating various power supply requirements
• Compact 6-lead SC-70 package, which is suitable for automated assembly processes and saves board space

The device is also characterized by its robust performance in harsh environments, making it suitable for use in automotive, industrial, and consumer applications where reliability is paramount. The AD5246BKSZ10-RL7 can be used in applications such as LED brightness control, adjustable gain control for amplifiers, and parameter adjustment in electronic systems.

With its precision, programmability, and small form factor, the AD5246BKSZ10-RL7 from Analog Devices Inc. is an excellent choice for designers looking to add flexible resistance tuning capabilities to their electronic designs. Its ease of use, combined with the reputation of Analog Devices for high-quality and reliable components, ensures that this digital potentiometer will be a valuable addition to a wide range of electronic products.
