The AD5290YRMZ100 is a high-performance, single-channel digital potentiometer brought to you by Analog Devices Inc., a leader in precision high-performance integrated circuits. This device offers a compact and precise solution for applications requiring digitally controlled resistance settings.

Key Features

• Resistance Options: The AD5290YRMZ100 provides a 100 kΩ end-to-end resistance value, offering a fine resolution for various applications.
• High Performance: With a 1% end-to-end resistor tolerance, the device ensures accuracy and consistency in performance.
• Single Supply Operation: It operates from a 2.7 V to 5.5 V single supply, making it versatile for both low-voltage and standard applications.
• Programmable: The digital potentiometer can be programmed via a SPI-compatible serial interface, allowing for easy adjustment and control.
• Nonvolatile Memory: It features a nonvolatile memory (EEPROM) to retain the resistance setting even when the power is off, ensuring persistent operation across power cycles.
• Low Temperature Coefficient: The device boasts a low temperature coefficient, enhancing stability over varying temperatures.

Applications

The AD5290YRMZ100 is ideal for a wide range of applications such as:

• Automated Test Equipment (ATE)
• Industrial Automation
• Instrumentation
• Data Acquisition Systems
• Digital Gain and Offset Adjustment

Package and Quality

The device comes in a compact 10-lead MSOP (Mini Small Outline Package) that is RoHS compliant and suitable for space-constrained applications. Analog Devices Inc. ensures high-quality manufacturing standards, making the AD5290YRMZ100 a reliable choice for precision electronic designs.

Ordering Information

To order or obtain more information about the AD5290YRMZ100 digital potentiometer, please visit the Analog Devices Inc. website or contact an authorized distributor. Ensure the part number AD5290YRMZ100 is referenced to get the exact product specifications described here.
