The AD5293BRUZ-100 is a high-performance digital potentiometer manufactured by Analog Devices Inc., a leader in precision high-performance integrated circuits. This digital potentiometer offers a compact and precise solution for applications requiring variable resistance settings controlled digitally. It is part of the AD5293 series, known for its high accuracy and reliability.

Key Features

• Resistance Value: The device features a 100 kΩ end-to-end resistance with a ±1% tolerance, providing precise control over a wide range of resistance values.
• Resolution: It offers a 20-bit resolution, allowing for fine adjustments with 1,048,576 wiper positions, which makes it one of the most precise digital potentiometers available on the market.
• Interface: The AD5293BRUZ-100 uses a Serial Peripheral Interface (SPI) for easy communication with microcontrollers and other digital systems.
• Voltage Range: The device operates within a wide voltage range of 2.7V to 5.5V, making it versatile for various applications.
• Temperature Range: It is designed to perform reliably in a broad temperature range from -40°C to +125°C, suitable for demanding environments.
• Packaging: The digital potentiometer comes in a compact 14-lead TSSOP (Thin Shrink Small Outline Package), ideal for space-constrained applications.

Applications

The AD5293BRUZ-100 is well-suited for a variety of applications across different industries. It can be used in:

• Automated Test Equipment (ATE)
• Industrial Automation Systems
• Programmable Logic Controllers (PLC)
• Data Acquisition Systems
• Medical Equipment
• Communication Infrastructure

Quality and Reliability

Analog Devices Inc. is committed to providing products that meet the highest standards of quality and reliability. The AD5293BRUZ-100 is built with this commitment in mind, ensuring consistent performance and durability for the life of your product. Whether for industrial, medical, or communication applications, this digital potentiometer offers a reliable solution for precise resistance adjustments.
