Product Overview: AD5667RBRMZ-2 by Analog Devices Inc.

The AD5667RBRMZ-2, from Analog Devices Inc., is a high-precision, dual, 16-bit digital-to-analog converter (DAC) designed to deliver exceptional performance and accuracy for a wide range of applications. Its compact size, encapsulated in a 10-lead MSOP package, makes it an ideal choice for space-constrained applications.

This device operates from a single 2.7V to 5.5V supply, providing flexibility for various power requirements. The AD5667RBRMZ-2 features an on-chip reference with a 2 ppm/°C temperature coefficient and a power-on reset circuit that ensures the DAC output powers up to zero volts and remains there until a valid write to the device takes place.

The DAC utilizes a versatile 3-wire serial interface that operates at clock rates up to 50 MHz and is compatible with standard SPI, QSPI™, MICROWIRE™, and DSP interface standards. This interface, coupled with the device's daisy-chain capability, makes it simple to use in complex digital systems and reduces the number of digital lines required for multiple DAC setups.

The AD5667RBRMZ-2 is designed to offer high accuracy and low power consumption, making it suitable for portable battery-operated equipment. The DAC's low power consumption extends battery life, and its fast settling time allows for quick and accurate control signals. This makes it an excellent choice for applications such as programmable voltage and current sources, digital gain and offset adjustment, and test equipment.

Additionally, the product features a user-selectable gain setting, which allows the output range to be set at 0 V to VREF or 0 V to 2xVREF. The internal reference and gain settings are stored in on-chip, non-volatile memory (EEPROM), ensuring device configuration is maintained between power cycles.

In summary, the AD5667RBRMZ-2 from Analog Devices Inc. offers a combination of high performance, ease of use, and flexibility, making it an excellent choice for high-resolution analog output applications.
