Product Overview: AD620BRZ-RL by Analog Devices Inc.

The AD620BRZ-RL, manufactured by Analog Devices Inc., is a high-performance, low-power instrumentation amplifier that offers a perfect balance of specifications needed for precise, low-noise amplification of small signals. Its versatility and ease of use make it an excellent choice for a wide range of applications, including medical instrumentation, industrial process controls, and battery-powered devices.

Key Features

• Low Power Consumption: The AD620BRZ-RL operates with a quiescent current of just 1.3 mA max, which is ideal for power-sensitive applications.
• Wide Power Supply Range: It functions with a single power supply ranging from +2.3 V to +18 V, or dual supplies of ±2.3 V to ±18 V.
• High Accuracy: The device features a low input bias current of 1.0 nA max, a low offset voltage of 50 µV max, and an input offset drift of less than 0.6 µV/°C, ensuring high precision in signal amplification.
• Flexible Gain Settings: The AD620BRZ-RL can be easily configured to different gain settings with a single external resistor, and it offers a wide range of gain from 1 to 10,000.
• Excellent Common-Mode Rejection: It boasts a high common-mode rejection ratio (CMRR) of 120 dB min at G = 100, which is critical for applications where common-mode noise is present.

Applications

The AD620BRZ-RL is suitable for multiple applications that require accurate and reliable signal conditioning. Some of the typical applications include:

• ECG and medical instrumentation
• Transducer interfaces
• Industrial process controls
• Data acquisition systems
• Battery-powered and portable equipment

Reliability and Packaging

The AD620BRZ-RL comes in a robust SOIC-8 package, ensuring long-term reliability even in harsh industrial environments. This packaging also allows for easy integration into a wide range of electronic assemblies.

With its exceptional balance of performance features, the AD620BRZ-RL from Analog Devices Inc. stands out as a top choice for professionals seeking a reliable and efficient solution for signal amplification needs.
