AD629BRZ-R7

Part No AD629BRZ-R7
Manufacturer Analog Devices Inc.
Catalog Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Description IC OPAMP DIFF 500KHZ 8SOIC
Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Analog Devices Inc.
Packaging Reel - TR
Status Active
Amplifier Type Differential
Number of Circuits 1
Slew Rate 2.1 V/μs
-3db Bandwidth 500kHz
Voltage - Input Offset 100μV
Operating Supply Current 900μA
Channel Output Current 25mA
Supply Voltage - Operating 5 V to 36 V, ±2.5 V to 18 V
Temperature Range - Operating -40°C to 85°C
Mounting SMD (SMT)
Case / Package 8-SOIC
Win Source Part Number 008058-AD629BRZ-R7
Family Name AD629
Introduction Date October 01, 1999
ECCN EAR99
Country of Origin China
Halogen Free Compliant
Estimated EOL Date 2027
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Application Field Used in Signal Processing
Ultra Librarian 3D Model Ultra Librarian AD629BRZ-R7 CAD Model

Description

Product Overview: AD629BRZ-R7

The AD629BRZ-R7 is a high-performance differential amplifier designed and manufactured by Analog Devices Inc., a leader in precision signal processing technology. This particular component is engineered to simplify the task of measuring electrical signals in the presence of high common-mode voltages, which is a common challenge in industrial, medical, and automotive applications.

Key Features

  • Wide Input Voltage Range: The AD629BRZ-R7 can handle a wide range of common-mode voltages, making it versatile for various applications.
  • High Common-Mode Rejection Ratio (CMRR): With a CMRR of 86 dB (min) at 60 Hz, this amplifier can effectively minimize the influence of common-mode noise, ensuring accurate signal measurement.
  • Low Offset Voltage: The device features a low offset voltage, which contributes to its high accuracy in signal amplification.
  • Single or Dual Supply Operation: It offers flexibility in design, as it can be powered by a single supply ranging from +4.5 V to +36 V or a dual supply from ±2.25 V to ±18 V.
  • Robust Industrial Design: Encased in an 8-lead SOIC package, the AD629BRZ-R7 is designed to withstand the rigors of industrial environments.

Applications

The AD629BRZ-R7 is well-suited for a variety of applications where precision signal amplification is required in the presence of high common-mode voltages. Some of these applications include:

  • Motor control feedback systems
  • Battery-powered and portable devices
  • Industrial process controls
  • Data acquisition systems
  • Medical instrumentation such as ECG and EEG monitors
  • Automotive battery monitoring systems

Quality and Reliability

Analog Devices Inc. is known for its commitment to quality and reliability, and the AD629BRZ-R7 is no exception. Each unit is rigorously tested to ensure optimal performance and durability, making it a reliable choice for critical applications where precision is paramount.

Ordering Information

The AD629BRZ-R7 is available in tape and reel packaging, facilitating efficient handling and assembly during the manufacturing process. Its part number reflects the specific package and quantity configuration, ensuring you receive the correct version for your application needs.
