Product Overview: AD680ARZ Voltage Reference

The AD680ARZ is a precision, low power, bandgap voltage reference in a small SOIC package, produced by Analog Devices Inc., a renowned leader in high-performance semiconductors. This voltage reference provides a stable 2.5 V output voltage with a tight initial accuracy of ±1% and excellent temperature stability, making it an ideal choice for precision data conversion systems and battery-powered devices.

Key Features

• Output Voltage: Fixed 2.5V with high precision.
• Initial Accuracy: ±1% maximum for B grade.
• Temperature Coefficient: 10 ppm/°C maximum for B grade, ensuring reliable performance over a wide temperature range.
• Supply Range: 4.5 V to 36 V operation, making it versatile for various applications.
• Low Quiescent Current: Typically 15 µA, ideal for battery-powered applications.
• Short-Circuit Protection: Provides robustness and reliability in the event of a fault condition.
• Low Dropout Performance: Operates with a low voltage drop, enhancing efficiency.
• Package: Available in an 8-lead SOIC package that is compact and suitable for space-constrained applications.

Applications

The AD680ARZ is versatile and can be used in a wide range of applications, including:

• Precision data acquisition systems.
• Battery-powered equipment.
• Digital voltmeters and other measurement devices.
• Industrial control systems.
• Portable instrumentation.

Quality and Reliability

Analog Devices Inc. is committed to providing high-quality products. The AD680ARZ voltage reference is built with this commitment in mind, ensuring reliability and performance for critical applications. With its robust design and comprehensive testing, the AD680ARZ stands out as a reliable component for precision voltage regulation.
