The AD8047ARZ is a high-performance voltage feedback amplifier developed by Analog Devices Inc., a leader in precision high-performance electronics. Designed to deliver fast settling times and low distortion, this amplifier is an ideal choice for a wide range of applications, including telecommunications, imaging systems, and ATE equipment.

Key Features

• High Speed: The AD8047ARZ boasts a slew rate of 3000 V/µs, ensuring rapid response to input signal changes. This makes it particularly suitable for high-speed signal processing applications.
• Wide Bandwidth: With a gain bandwidth product of 250 MHz, this amplifier can handle a broad range of frequencies, maintaining a consistent gain throughout.
• Low Distortion: The device provides excellent signal fidelity with low harmonic distortion, which is critical for high-precision applications.
• Dual Supply Operation: It operates on dual supplies ranging from ±2.5 V to ±6 V, or a single supply from 5 V to 12 V, offering flexibility in various circuit designs.
• Robust Output Drive: Capable of driving capacitive loads up to 45 pF, the AD8047ARZ is robust and reliable in driving various output configurations.

Applications

The versatility of the AD8047ARZ makes it suitable for a multitude of applications. It is commonly used in:

• Active filters
• Video and RF amplification
• Cable drivers
• ADC/DAC buffers
• Test and measurement equipment

Package and Quality

The AD8047ARZ comes in an 8-lead SOIC package, which is compact and suitable for space-constrained applications. Analog Devices Inc. ensures high reliability and performance, with rigorous testing and quality control processes in place for their products.

Ordering Information

When ordering this amplifier, use the complete part number AD8047ARZ to specify the 8-lead SOIC package. For detailed specifications, application notes, and additional resources, visit the Analog Devices Inc. website.
