The AD8561ARUZ-REEL is a high-performance, ultrafast single supply comparator from Analog Devices Inc., designed to deliver exceptional speed with a propagation delay of just 7 ns. This component is part of the REEL packaging series, making it suitable for automated assembly processes and high-volume production environments.

This comparator operates from a single 5 V supply, which simplifies the design by eliminating the need for dual supplies. The single supply operation, combined with a wide input voltage range and rail-to-rail output, makes the AD8561ARUZ-REEL an ideal choice for high-speed applications that require low power consumption and efficient use of board space.

Key Features:

• Ultrafast Propagation Delay: 7 ns (maximum), which is critical for timing-critical applications.
• Single Supply Operation: Ranges from 4.5 V to 5.5 V, simplifying power supply design.
• Low Power Consumption: Offers a balance between speed and power efficiency, making it suitable for portable and battery-powered applications.
• Rail-to-Rail Output: Provides maximum dynamic range, which is especially useful in single-supply systems.
• Latch Function: With a latch enable feature, the output can be held at its current state, providing additional flexibility in timing design.

Applications:

• High-speed signal processing
• Line receivers
• Window comparators
• Pulse and square wave generators
• High-speed triggers
• System monitoring and control

The AD8561ARUZ-REEL comes in a compact TSSOP package, which is ideal for space-constrained applications. Its robust design ensures reliable performance in a wide range of operating conditions, making it a versatile choice for designers looking to enhance the speed and efficiency of their electronic systems. With its combination of ultrafast speed, single supply operation, and low power consumption, the AD8561ARUZ-REEL stands out as a superior solution for a multitude of high-speed comparison tasks.
