AD8606AR-REEL

Part No AD8606AR-REEL
Manufacturer Analog Devices Inc.
Catalog Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Description IC OPAMP GP 10MHZ RRO 8SOIC
Datasheet
Sample
Rohs State Need to verify
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Analog Devices Inc.
Packaging Reel - TR
Status Obsolete(EOL)
Amplifier Type General Purpose
Number of Circuits 2
Output Type Rail-to-Rail
Slew Rate 5 V/μs
Gain Bandwidth Product (GBP) 10MHz
Current - Input Bias 0.2pA
Voltage - Input Offset 80μV
Operating Supply Current 1mA
Channel Output Current 80mA
Supply Voltage - Operating 2.7 V to 5.5 V
Temperature Range - Operating -40°C to 125°C
Mounting SMD (SMT)
Case / Package 8-SOIC
Win Source Part Number 1013546-AD8606AR-REEL
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian AD8606AR-REEL CAD Model

Description

The AD8606AR-REEL from Analog Devices Inc. is a high-precision, low-power operational amplifier that offers a perfect blend of features to cater to a wide range of applications. This dual operational amplifier is part of the renowned AD8606 series, known for its excellent performance in terms of accuracy and stability.

Key Features

  • Rail-to-Rail Input/Output: The AD8606AR-REEL can operate with input and output signals very close to the supply rails, enhancing the dynamic range in single-supply applications.
  • Low Offset Voltage: With a typical offset voltage of just 65 µV, this operational amplifier ensures high accuracy in signal conditioning tasks.
  • Low Input Bias Current: The device exhibits an input bias current of only 1 pA, making it suitable for high-impedance sensor interfaces and precision integrators.
  • Single-Supply Operation: It can operate from a single 2.7 V to 5.5 V supply, which is ideal for battery-powered devices and portable equipment.
  • Low Power Consumption: The AD8606AR-REEL is designed for power-sensitive applications, featuring a low supply current of 1 mA per amplifier.
  • Extended Temperature Range: This device is operational over the extended industrial temperature range of -40°C to +125°C, making it suitable for harsh environments.

Applications

The AD8606AR-REEL precision amplifier is versatile and can be used in a variety of applications, including:

  • Portable and battery-powered equipment
  • Medical instrumentation
  • Sensor signal conditioning
  • Data acquisition systems
  • Active filters
  • Notebook and PDA audio circuits

Packaging and Availability

The AD8606AR-REEL precision amplifier comes in a compact surface-mount package and is supplied in tape and reel form, which is suitable for automated assembly processes. This product is available for purchase from Analog Devices Inc. and its authorized distributors, ensuring easy integration into your next project.
