AD9238BSTZ-40

Part No AD9238BSTZ-40
Manufacturer Analog Devices Inc.
Catalog Data Acquisition - Analog to Digital Converters (ADC)
Description IC ADC 12BIT DUAL 40MSPS 64-LQFP
Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Analog Devices Inc.
Packaging Tray
Status Active
Number of Bits 12
Sampling Rate 40M
Number of Inputs 2
Input Type Differential, Single Ended
Data Interface Parallel
Configuration S/H-ADC
Number of A/D Converters 2
Reference Type External, Internal
Analog Supply Voltage 2.7 V to 3.6 V
Digital Supply Voltage 2.25 V to 3.6 V
Features Simultaneous Sampling
Temperature Range - Operating -40°C to 85°C
Case / Package 64-LQFP (7x7)
Win Source Part Number 077318-AD9238BSTZ-40
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian AD9238BSTZ-40 CAD Model

Description

Product Overview: AD9238BSTZ-40 by Analog Devices Inc.

The AD9238BSTZ-40 is a state-of-the-art dual-channel, 12-bit Analog-to-Digital Converter (ADC) developed by the renowned semiconductor manufacturer, Analog Devices Inc. This high-performance component is designed to operate at a sample rate of up to 40 MSPS (Mega Samples Per Second), providing exceptional accuracy and speed for a wide range of applications, including medical imaging, communications, and industrial instrumentation.

Key Features

  • Resolution: 12-bit ADC with dual channels for simultaneous sampling
  • Sample Rate: Up to 40 MSPS, enabling high-speed data acquisition
  • Input Range: Flexible input range that can be adjusted to fit various signal requirements
  • Data Interface: LVDS (Low Voltage Differential Signaling) outputs for reduced noise and high-speed data transfer
  • Package: Supplied in a compact 48-lead LQFP (Low-profile Quad Flat Package), ideal for space-constrained applications
  • Power Efficiency: Low power consumption design, suitable for power-sensitive applications

Performance and Quality

The AD9238BSTZ-40 is built with Analog Devices' proprietary IC design, ensuring superior performance and signal fidelity. Its robust architecture allows for consistent and reliable operation even in the most demanding environments. The device features an on-chip reference and a sample-and-hold circuit, which contribute to its high level of accuracy and minimize external component requirements.

Applications

Due to its high-speed sampling capabilities and excellent accuracy, the AD9238BSTZ-40 is an ideal choice for a variety of advanced applications. It is particularly well-suited for:

  • Medical Imaging Systems
  • Wireless and Wired Communications
  • Radar and Satellite Systems
  • Test and Measurement Equipment
  • Industrial Process Control

Ordering and Support

Customers can order the AD9238BSTZ-40 directly from Analog Devices Inc. or through their authorized distributors. Analog Devices provides comprehensive technical support, including datasheets, reference designs, and application notes to assist with the integration of the AD9238BSTZ-40 into your next project.
