ADG1404YRUZ High-Performance Analog Multiplexer

The ADG1404YRUZ is a high-performance, monolithic analog multiplexer from Analog Devices Inc., a renowned leader in the semiconductor industry. This component is part of the robust ADG1400 series, which is known for its reliability and efficiency in routing analog signals in various electronic systems.

Constructed with Analog Devices' proprietary iCMOS® (industrial CMOS) technology, the ADG1404YRUZ offers a superior combination of high voltage handling capability and low on-resistance, making it an ideal choice for precision analog switching applications. The device features four single-pole/single-throw (SPST) switches, providing the user with a versatile tool for signal routing.

One of the standout features of the ADG1404YRUZ is its wide signal range, which allows the device to handle ±15 V dual supplies or a 30 V single supply. This wide range ensures compatibility with a variety of signal levels, making it a flexible option for designers. Additionally, the low on-resistance (typically 1.5 Ω) minimizes signal distortion and ensures high signal integrity, which is crucial in precision applications.

The ADG1404YRUZ also boasts a low total harmonic distortion (THD) and low charge injection, which further contributes to the preservation of signal fidelity. With fast switching times (t_ON and t_OFF), the device is well-suited for applications requiring rapid signal routing, such as data acquisition systems, test equipment, and audio and video switching.

The compact TSSOP (Thin Shrink Small Outline Package) packaging of the ADG1404YRUZ makes it an excellent choice for space-constrained applications. It also features a digital interface that is compatible with TTL and CMOS levels, ensuring easy integration into digital systems. Furthermore, the device includes built-in overvoltage protection, safeguarding the multiplexer from short-term overvoltage events, which enhances the longevity and reliability of the component.

In summary, the ADG1404YRUZ from Analog Devices Inc. stands out as a high-quality, flexible solution for designers looking to incorporate a robust analog multiplexer into their electronic designs. Its combination of performance, durability, and versatility makes it an excellent choice for a wide range of applications.
